Grooving machine is specially designed for notching V type groove ,used for industrial cardboard, greyboard, MDF boards and the other cardboard.
It adopts new way of transportation structure, wrap the cardboard on the entire surface of the roller(the diameter 60cm),it guarantees the groove more accurately, no deviation and be straight, the machine has the features of high accuracy, fast speed and with durable cutting blade.
Width of material |
100-950mm |
Length of cardboard |
100-950mm |
Distance of each groove |
0-830mm |
Thickness of material |
300GSM-3.6mm |
Grooving degree |
90-130 degree adjustable |
The number of groove |
9 sets one time |
Production speed |
10-35M/Min |
Power |
3.7KW |
Dimension (L*W*H) |
1500mm*1400mm*1600mm |
Weight |
1380KGS |
Video link |
|
