Professional Cardboard Grooving
Machine Manufacturer
Feature:
- Mechanical automatic feeding system.
- Auto-correcting function to keep accuracy and reduce error.
- Waste material will be sent out automatically after grooved.
- Final product will be collected automatically.
- Auto-stop system for board seized up.
- Two feeding section and bidirectional receiving
- Each cutting blade could move left and right.
- The counter is used for record the number of production.
- The wheel is used for adjust grooving degree from80°-135°.
- Special use blade grinder and usually it needs two minutes for grinding one piece of cutting blade
|
Product name |
High speed automatic grooving machine |
|
|
Model |
KLG-950 |
SLG-950L |
|
Material width |
100-850mm |
120-1200mm |
|
Material Length |
100-450mm |
120-550mm |
|
Best accuracy |
±0.05mm |
|
|
The fastest speed |
220-260PCS/Min (work piece size 150*150mm) |
|
|
Grooving degree |
80-110°，110-135° adjustable |
|
|
Groover quantity |
9 |
|
|
Power |
2.5KW |
|
|
Machine dimension |
1800*1300*1350 |
2000*1920*1500mm |
|
Wooden case dimension |
2100*1750*1770mm |
2200*2120*1770mm |
|
Certificate |
CE |
|
|
Weight |
1600KGS |
1900KGS |
|
Accessory |
1 EA grinder of knife |
|
|
1 tool box:1set Allen wrench, straight screwdriver of 4 inch, open spanner, adjustable wrench, grater, instruction manual of inveter |
||
|
20 PCS blades of V shape |
||
|
