Professional Cardboard Grooving
Machine Manufacturer
The machine mainly includes 4 parts: the first slotting part, the collecting and conveying part, the second slotting part, and the special conveyor belt for cardboard output.
|
Size of first grooving |
Length 100-550mm, width 100-600mm |
|
Size of second grooving |
Length 100-600mm, width 100-600mm |
|
Material thickness |
1.0-3.0mm |
|
Grooving accuracy |
±0.1mm |
|
Grooving angle |
90-130degree adjustable |
|
Grooving tool on the first step |
8sets |
|
Grooving tool on the second step |
4sets |
|
Big Drum number |
3 |
|
Machine power |
6KW |
|
Speed |
80-120PCS/Min (300*300) |
|
Main dimension |
2635*3900*1445mm |
|
Weight |
3200KGS |
|
Function : 1 Auto feeding →crosswise grooving →collecting →conveying →lengthwise grooving→Auto collector |
|
|
Video link :https://youtu.be/UG7f74dxpFg |
|
