Slitting machine operating procedures

Slitting machine operating procedures

1、Start-up inspection

Slitting machine before the start, slitter inspection of the parts of the screws are loose, the sealing parts are not leaking phenomenon, the work Whether the environment is clean.

Ensure that no one is near the rotating equipment, turn on the main switch.

Check whether the unwinding shaft is in the working position and make sure the shaft head is effectively clamped.

Confirm that the above checks are qualified before you can start working.

2、Starting operation

According to the production order and production process requirements, set the slitting machine roll length and tension.

2.2 Introduce the cloth head to the slitter according to the requirements of the cloth.

2.3 Adjust the slitting knife according to the production order requirements.

2.4 Set the paper management according to the knife size and push the winding air expansion shaft into the work station.

2.5 After clamping the air expansion shaft, open the slitter slowly pull out the lifting head, slitting knife into the knife, wait for the slitting mouth through the paper tube

Stop the slitting machine, cut the knife to cut off the head cloth, the paper tube, gas expansion shaft inflation and the head of the cloth into the winding gas expansion shaft.
